AMDP 2022-2024 6.7L CUMMINS EFILIVE CUSTOM TUNING

AMDP 2022-2024 6.7L Cummins EFILIVE Custom Tuning with NO ECM SWAP Required is now available.

Currently, this is a ZERO HP file with Emissions Removed.

Underhood EGR can be completely removed on this file.

Throttle valve needs to remain plugged in.

This file requires switching the MAP sensor to Cummins PN:2897334

This product only supports 68RFE equipped trucks so NO High Output Aisin or Cab and Chassis trucks.

This product cannot add trans tuning, this is ECM tuning ONLY.

If the customer wishes to upgrade to ECM SWAP power-added tuning in the future there will be a separate item with that upgrade option as we will apply some credit towards that purchase.

Before proceeding with this tuning, we recommend using an MPVI3 and pulling a read from the ECM. This will serve as a recovery file if you have any kind of failure or interruption during flashing.

Instructions for flashing through the OBD:

1. After ordering you will receive your vehicle tune file emailed to you from us.
2. Before you begin, ensure your device firmware and EFI software are up to date.
3. Install Cummins Security Bypass cable
4. Place key in RUN position (DO NOT START) and remove fuses numbered: 49,51,33,54,57,66,82,88 to prevent any BUS flashing issues. Yes, you interior lights and dash will shut off when you pull the fuses.

5. Flash tune file with your EFILive device.
6. When complete, reinstall fuses and you're good to go!

Note: If flashing ECM on bench, or using BenchForce harness to connect directly to the ECM, it is not required to do anything with the vehicle fuses. Just flash directly into the ECM like normal.
